9. CINELITE Display
9-5
9.5 Displaying Luminance Levels as Percentages or RGB Values
In the percentage and RGB display, you can display luminance levels as level percentages,
RGB percentages, or using 255 RGB levels. The measured values are typically displayed
using white, but they are displayed using yellow when the luminance level is 80 % or more or
0 % or less.
• LEVEL% display
Luminance levels are indicated as percentages. This is the default setting.
Figure 9-4 LEVEL% display
• RGB% display
Each R, G, and B luminance level is indicated using a percentage. The levels are also
indicated using bars on the left side of the display (the order is R, G, and then B).
Figure 9-5 RGB% display
To Next Page
