11. Video Signal Waveform Display
11-10
11.6 Line Selection Settings
To configure the line select settings, press F•4 LINE SELECT in the video signal waveform
menu. You can display the waveform of the selected line.
WFM → F•4 LINE SELECT →
Figure 11-12 LINE SELECT menu
11.6.1 Displaying the Waveform of the Selected Line
To display the waveform of the selected line, follow the procedure below.
Changing this setting will also change the picture display and vector display line selection
settings.
Procedure
WFM → F•4 LINE SELECT → F•1 LINE SELECT
Settings
ON: The waveform of the selected line is displayed.
OFF: The waveforms of all lines are displayed on top of each other. This is the
default setting.
LINE SELECT = ON LINE SELECT = OFF
Figure 11-13 Turning line selection on and off
11.6.2 Selecting a Line
To select a line to display the waveform of, follow the procedure below. The selected line is
indicated in the lower left of the display.
Changing this setting will also change the selected line in the picture, CINELITE, vector,
and status (data dump) displays.
Procedure
WFM → F•4 LINE SELECT → F•D
To Next Page
