HBS86 and HBS86H Micro Step Resolution Setting
Steps/Revolution SW1 SW2 SW3 SW4
Software Configured
(Default 200)
on on on on
800
off on on on
1600 (Factory Setting)
on off on on
3200
off off on on
6400
on on off on
12800
off on off on
25600
on off off on
51200
off off off on
1000
on on on off
2000
off on on off
4000
on off on off
5000
off off on off
8000
on on off off
10000
off on off off
20000
on off off off
40000
off off off off
Configuring HBS Drive in PC Software
Please consult the Connecting to PC Software chapter for how to connect the HBS drive to PC.
Suppose the tuning software has been open, click the Drive->Parameters to open the Tool->Drive
Parameters window. Double click the Value column to modify the parameter. Don’t forget to click
Download to Drive to store the change to drive’s NVM. Please consult the HBS Drive Configuration
chapter for the recommended settings of different HBS motor. Please refer to the software manual
for more information.
