Leadshine HBS86H - Running DirectionSetting; Micro stepsSetting

-13-
6.2 Running DirectionSetting
SW2 is used for setting the running direction, “off” means CCW,
while “on” means CW.
6.3 Micro stepsSetting
The micro steps setting is in thefollowingtable, whileSW3 、
SW4 、 SW5 、 SW6 are all on, the internal default micro steps inside is activate，
this ratio can be setting through the HISU.
Dial switch
Micro steps
SW3
SW4
SW5
SW6
Default
on
on
on
on
800
off
on
on
on
1600
on
off
on
on
3200
off
off
on
on
6400
on
on
off
on
12800
off
on
off
on
25600
on
off
off
on
51200
off
off
off
on
1000
on
on
on
off
2000
off
on
on
off
4000
on
off
on
off
5000
off
off
on
off
