3. Ports Introduction
3.1 ALM and PEND signal outputports
1
2
3
4
Port
Symbol
Name
Remark
1
PEND+
In position signal output +
+
-
2
PEND-
In position signal output -
3
ALM+
Alarm output +
4
ALM-
Alarm output -
3.2 Control Signal InputPorts
1
2
3
4
5
6
