Leadshine HBS86H - Connections to CommonCathode

-9-
5.2 Connections to CommonCathode
Remark:
VCC is compatible with 5V or 24V;
R(3~5K) must be connected to control signal terminal.
Controller
Pulse
Signal
VCC
2HSS86H-KH
Drive
PUL+
270
VCC
Direction
Signal
PUL-
DIR+
270
VCC
Enable
Signal
DIR-
ENA+
270
VCC
ENA-
R
PEND+
VCC
R
PEND-
ALM+
ALM-
