Documenting Results
WaveJet provides a front panel USB port for a quick and easy
way to save waveforms, screen captures, and setups.
Connect a USB memory device to the front panel USB port.
Press the front panel Print button to store a
screen capture to a USB memory device.
Set user preferences in the Utilities menu to
select file type, file name, and background
color.
Press the front panel Save/Recall button to access the
Save/Recall Menu.
In this menu save waveforms to USB memory in either
ASCII or binary formats, and save and recall setup files
from internal memory or from USB memory.
The Save/Recall menu is where the selection to recall the
Default Setup is located.
The rear panel USB port allows for printing
screen captures and can also be used for
remote control from a computer.
