LEGRAND D45 SYSTEM User Manual

125
321010Colour 5.6” handsfree indoor handset
Configuration settings by device keyboard - WAY 1:
INSTALLATION SETTINGS OPERATION LIST TABLE
SETUP OPERATION CODE AND
LIGHT STATUS
NEXT
OPERATION
MEANING AND INFORMATION FOR THE OPERATION REMARK
Set infrared sensor 23#
Message light is o. 8 alarm
lights will indicate status of
infrared sensor. Setting: infrared
sensor: light of this alarm zone
will be on. Non-infrared sensor,
light of this alarm defence area
zone will be o.
5# 1 infrared sensor for alarm zone 5: LED 5 on, 1 long tone
0 non- infrared sensor for alarm zone 5: LED 5 on, 1 long tone
* return to previous menu, 1 short tone
other unsuccessful operation: 3 short tones
…… … … Note: 1/2/3/4 alarm zone are
dened as infrared alarm zones,
door alarm, smoke alarm, gas
alarm. They cannot be changed.
5/7 are defaulted as infrared alarm
zones s. 6/8 alarm are defaulted as
non-infrared alarm zones
8# 1 infrared sensor for alarm zone 8: LED 8 on, 1 long tone
0 Non-
infrared sensor for alarm zone 8: LED 8 on, 1 long tone
* return to previous menu, 1 short tone
other unsuccessful operation: 3 short tones
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
Setting for Time
delay after alarm set
24#
The light of the zone indicates
the parameter For example, if the
parameter is 3, then LED 3 will on
1 delay 40 s: 1 long tone, only LED 1 will on Default: 100 s
only for thief area alarm
2 delay 100 s: 1 long tone, only LED 2 will on
3 delay 150 s: 1 long tone, only LED 3 will on
4 delay 210 s: 1 long tone, only LED 4 will on
5 delay 255 s: 1 long tone, only LED 5 will on
* return to main menu of installation setup, 1 short tone
Other unsuccessful operation: 3 short tones
Setting for Time
delay after alarm
happens
25#
The light of defence area give the
parameter. For example, if the
parameter is 3, then LED 3 will on
1 delay 40 s: 1 long tone, only LED 1 will on Default: 40 s
only for thief area alarm
2 delay 100 s: 1 long tone, only LED 2 will on
3 delay 150 s: 1 long tone, only LED 3 will on
4 delay 210 s: 1 long tone, only LED 4 will on
5 delay 255 s: 1 long tone, only LED 5 will on
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
Enable and disable
sound alarm for thief
26#
The Information LED indicates the
setup state
1
enabled: if there is a burglar alarm, loudspeaker will emit a sound. Message light
on, 1 long tone
Default: no sound
0
disabled: if there is a burglar alarm, loudspeaker will not emit a sound. Message
light o, 1 long tone.
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
* exit main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
1)
Doorbell function
setup(if is doorbell
function , it is not
Small EP function)
16#
The information LED to give
setup state
1 Enable doorbell function, the information LED is on, 1 long tone. Default: is not doorbell function, tt
is Small EP function.
0 Disable doorbell function, the information LED is o, 1 long tone
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
2)
Handset connection
to Apartment inter-
face function setup
13#
The information LED to give
setup state
1 handset has connected to the Apartment interface the information LED is on, 1 long
tone,
Default: Handset not connected to
the Apartment interface.
0 handset has not connected to the Apartment interface, the information LED is o, 1 long
tone.
* return to main menu of installation setup, 1 short tone
other unsuccessful operation: 3 short tones
BT00468-b-EN 15/05/2013
