nuMBerS
of riSer ShuntS
nuMBerS of floorS
# ff
nuMBerS of flatS/floor
#ii
nuMBer of apart. in
each unit/riSer
99 10 4 40
20 50 4 200
11 90 4 360
66 10 6 60
13 50 6 300
7 90 6 540
50 10 8 80
10 50 8 400
5 90 8 720
25 10 16 160
5 50 16 800
12 10 32 320
6 20 32 640
The flexible configuration can be
used in installation of up to 4000
apartments, with the maximum
limits listed in the linked table (that
can be shared with the people in
charge of the configuration – and can
be completed using how much row
we want to communicate).
The simplified configuration can be
applied to a simplified installation
or to a district of the complete
installation, inheriting the limits of
the chosen configuration type.
LEDs, etc. ) in order assign to the
device the designated number;
 use the PC on the eld to
physical configuraTion
(insTallaTion)
The devices may be configured in
three ways:
 Use of physical congurators: this
means placing the right numbered
congurators in the devices in the
right position (depending on the
design of the conguration);
 dene a procedure of
conguration of each device that
uses its resources (keypad, LCD,
total nuMBer of apartMentS in the
inStallation:
Virtually no liMitS
Number of apt. for each “district”
(AS02: LAN-8Wire interface)
4.000 apt. or villas.
Total number of units/riser for each district 400
Total number of apt./villas for each riser: 800 (if only 1 handset in each apt.)
Total number of apt./villas for each riser: 400 (if only 2 handsets in each apt.)
Total number of apt./villas for each riser: 265 (if only 3 handsets in each apt.)
Total number of apt./villas for each riser: 800 (up to 5 handsets in each apt. with D45 apt. interface)
download the results of the design
conguration done on a PC, on to
each device using its MAC address.
defaulT Behaviour of
aparTmenT funcTions
The default functions are available
both with simplified and flexible
system configuration.
The default functions are:
 Self-powering of the main riser EP;
 repeated pression on self power on
function changes on next address
riser EP;
 call to Switchboard is to main
Switchboard;
 alarm collected by main
Switchboard.
configuraTion mode for
The whole sysTem
Two configuration modes available,
configuration Mode 1 and
configuration Mode 2. The main
characteristics for each configuration
Mode are described below:
#ff
for each riSer
#ii
for each floor
can SySteM configuration Mode 1 Be uSed?
≤ 20 ≤4 YES, but it is necessary to calculate the total number of handsets for
whole system according to Mode 1 conguration. If the total number
calculated is 4000 or less, Mode 1 conguration is possible, if the total
number is over 4000, Mode 2 must be considered.
> 20 ≤ 4 NO
≤20 > 4 NO
> 20 > 4 NO
*1*: Below are the rules for system configuration (Mode 1).
41
