GENERAL RULES FOR INSTALLATION
The information of table 7 is based on
below conditions:
A) 50 m cable from Floor shunt
to handset.
B) 5 m cable between floors.
C) 0.5 m cable between Floor shunt
and Floor shunt in same floor for
projects with more than one floor
shunt on each floor.
D) Between Power supply and 1st
Floor shunt, for the connection use
2 wire cables.
Table 7: 323010 application on case 4, case 5, case 6, case 10, case 11 and case 12
How many apartments
on every oor
handSet
Case 4 Case 5 Case 6 Case 10 Case 11 Case 12
4 handsets/oor 4 2 3 6 4 5
8 handsets/oor 4 2 3 6 4 5
12 handsets/oor 4 2 3 6 4 5
16 handsets/oor 4 2 3 6 4 5
20 handsets/oor 4 2 3 6 4 5
24 handsets/oor 4 2 3 6 4 5
28 handsets/oor 4 2 3 6 4 5
32 handsets/oor 4 2 3 6 4 5
E) Auxiliary power supply without
smart function.
F) For any types of handsets not listed
in table 7 the information is the
same as table 4 to table 6.
G) For all handsets which connect to
the same auxiliary power supply
the display can be switched on at
the same time.
Remark: if small entrance panels are present, the
number of devices to be supplied by 323010 may
require to use more power supplies, increasing
the project cost.
We therefore suggest to use 323005 to setting
auxiliary power supply.
