53
Contents
1. Weights and dimensions ............. 54
2. Handling and unpacking .............. 55
3. Storage for fixed and draw-out breakers ... 57
4. Identification ....................... 58
5. Racking-out frontal cover ............. 59
6. Exploring .......................... 60
7. Operating .......................... 62
8. Technical specifications ............... 64
9. Features of the main
electrical accessories ................. 66
10. Installation and door cut-out .......... 68
11. Termination - Fixed version ........... 74
12. Termination - Draw-out version ....... 76
13. Connection for fixed version .......... 78
14. Possible connections
for draw out version ............... 79
15. Ground connection ................. 80
16. Loading in panel ................... 81
17. Auxiliary terminals block ............ 83
18. Cabling system . . . . . . . . . . . . . . . . . . . . 85
19. Electrical diagrams ................. 87
20. Setting up protection unit set up ...... 91
21. Standard functions of the breaker...... 93
22. DMX
3
start up ..................... 95
23. Ordinary maintenance .............. 99
24. Basic trouble shooting .............. 100
