LEGRAND DMX3 1600

54
DMX
3
1. Weights and dimensions
It is important to know the weight of the breaker for proper selection of handling equipment.
NOTE: net weights
Poles Circuit breakers
Switch
disconnectors
Fixed
3p 20 kg 17 kg
4p 25 kg 22 kg
Draw-out
3p 42 kg 39 kg
4p 52 kg 49 kg
DMX
3
-1600
Dimensions - xed version 3p (mm)
Width 254
Depth 203
Height 321
Dimensions - fixed version 4p
Width 324
Depth 203
Height 321
Dimensions - draw-out version 3p
Width 282
Depth 306
Height 352
Dimensions - draw-out version 4p
Width 352
Depth 306
Height 352
