CS10/CS15 & GS Sensors, Description of the System
25
2.5.2 CS15
Upside of CS15
Underside of CS15
a) Slot cover
b) Screen
c) Keyboard
d) Port cover
e) Power socket
f) USB A Host port
g) Docking station contacts
h) LEMO port (USB and serial)
i) USB Mini port
j) DSUB9 port
CS_002
f
e
g
h
i
j
b
a
c
d
a) Hand strap bottom clips
b) Hand strap
c) Battery compartment
d) Hand strap top clips
e) Slots
f) Slot cover
g) Stylus
h) GS06 contacts
i) SIM card slot
j) SD card slot
a
b
d
e
f
g
h
i
j
c
0012597_001
SD
