6.2.3 Technical Data
Description and use The table gives a description and the intended use of the GS05/GS06.
Dimensions
Connector 5 pin interface port
Weight
Power
Electrical data
Environmental
specifications
Temperature
Protection against water, dust and sand
Humidity
Type Description Use
GS05 L1 GPS, GLONASS SmartTrack antenna. With CS10 field controller.
GS06 L1 GPS, GLONASS SmartTrack antenna. With CS15 field controller.
Type Length [m] Width [m] Thickness [m]
GS05 with CS10 0.278 0.102 0.045
GS06 with CS15 0.323 0.125 0.045
Type Weight [kg]/[lbs]
GS05 with CS10 0.750/1.653
GS06 with CS15 0.910/2.006
Power consumption: 0.5 W typically, 45 mA
External supply voltage: Nominal 12 V DC ( ), voltage range 5 V-28 V DC
Type GS05/GS06
Voltage -
Current -
Frequency GPS L1 1575.42 MHz
GLONASS L1 1602.5625 MHz-1611.5 MHz
Gain Typically 27 dBi
Noise Figure Typically < 2 dBi
Operating temperature [°C] Storage temperature [°C]
-30 to +60 -40 to +80
Protection
IP67 (IEC 60529)
Dust tight
Protected against water jets
Waterproof to 1 m temporary immersion
Protection
Up to 100 %
The effects of condensation are to be effectively counteracted by periodically drying
out the antenna.
