CS10/CS15 & GS Sensors, Description of the System
26
2.6 Docking Station Components
Docking station
2.7 GS08plus/GS12 Components
GS08plus/GS12
components
a) Power socket
b) USB port
c) Docking station bracket
d) Docking station contacts
e) GEV223 data cable
CS_020
a
c
e
b
d
a) ON/OFF button
b) LEDs
c) LEMO port including USB port
d) Mechanical Reference Plane (MRP)
e) Clip-on contacts (only GS12)
f) Battery compartment
TRK
BT
PWR
ON
OFF
004097_001
a
b
c
d
e
f
