CS10/CS15 & GS Sensors, Operation
46
4.1.14 Enabling WiFi in WinCE
Enabling WiFi in
WinCE step-by-step
WiFi is only available for certain models.
4.2 Power Functions
Turning CS field
controller on
Press and hold power key ( ) for 2 s.
CS field controller must have a power supply.
Turning CS field
controller off
Press and hold power key ( ) for 5 s.
CS field controller must be on.
Putting CS field
controller into
stand-by
Press and hold power key ( ) < 2 s.
CS field controller must be on. The software must be in the Main Menu.
Power Options
menu
Press and hold power key ( ) for 2 s to open Power Options menu.
CS field controller must be on.
Turn on
GS08plus/GS12
To turn on the instrument press and hold the ON/OFF button for 2 s.
Turn off
GS08plus/GS12
To turn off the instrument press and hold the ON/OFF button for 2 s.
Step Description
1. Press Fn Minim to minimise SmartWorx.
2. Select Start\Settings\Network and Dial-Up Connections.
3. In the Network Connections window:
Tab the NXPWLAN1/OWL221A1 icon and select File\Enable.
OR
Hold the stylus on the NXPWLAN1/OWL221A1 icon. Select Enable from
the context menu.
Option Description
Turn off Turn CS field controller off.
Stand-by Put CS field controller into stand-by mode.
In stand-by mode, CS field controller shuts down
and reduces power consumption. Rebooting from
stand-by mode is quicker than a cold start after
turning off.
Lock keyboard Lock the keyboard. Option turns to Unlock keyboard.
Turn off touch screen Disable touch screen. Option turns to Turn on touch
screen.
Reset... Perform one of the following options:
• Restart (restarts Windows CE)
• Reset Windows CE (resets Windows CE and communi-
cation settings to factory defaults)
• Reset installed software (resets settings of all
installed software)
• Reset Windows CE and installed software (resets
Windows CE and settings of all installed software)
