CS10/CS15 & GS Sensors, Operation
45
Connect to PC via
USB cable step-by-
step
5. Check Yes, this time only. Next>.
6. Check Install the software automatically (Recommended). Next>. The
software for Remote NDIS based LGS CS Device will be installed on your
PC.
7. Finish.
8. The Found New Hardware Wizard starts up automatically a second time.
9. Check Yes, this time only. Next>.
10. Check Install the software automatically (Recommended). Next>. The
software for LGS CS USB Device will be installed on your PC.
11. Finish.
For PCs with Windows XP operating system:
12. Run the ActiveSync installation program if not already installed.
13. Allow USB connections inside the Connection Settings window of
ActiveSync.
For PCs with Windows Vista or Windows 7/Windows 8 operating system:
14. Windows Mobile Device Center starts up automatically. If does not start
automatically, start Windows Mobile Device Center.
Step Description
Step Description
1. Start the PC.
2. Plug the GEV234 cable into CS field controller.
For CS field controllers with DSUB9 connector, the GEV223 cable has
to be used.
3. Turn the CS field controller on.
4. Plug the GEV234 cable into the USB port of the PC.
For PCs with Windows XP operating system:
ActiveSync starts up automatically. If does not start automatically,
start ActiveSync. If not already installed, run the ActiveSync installa-
tion program.
5. Allow USB connections inside the Connection Settings window of
ActiveSync.
6. Click Explore in ActiveySync.
The folders on the CS field controller are displayed under Mobile
Devices. The folders of the data storage device can be found in
StorageCard.
For PCs with Windows Vista or Windows 7/Windows 8 operating system:
Windows Mobile Device Center starts up automatically. If does not
start automatically, start Windows Mobile Device Center.
CS_026
2
3
4
