CS10/CS15 & GS Sensors, Technical Data
64
6.5 Antennas Technical Data
Description and use The table gives a description and the intended use of the antenna.
Dimensions
Connector
Mounting
Weight
Electrical data
Environmental
specifications
Temperature
Protection against water, dust and sand
Humidity
Cable length
Type Description Use
AS05 L1 GPS, GLONASS SmartTrack+
antenna with built-in ground plane
With CS10/GS05, CS15/GS06
Type AS05
Height 6.2 cm
Diameter 17.0 cm
AS05: TNC female
AS05: 5/8" Whitworth
AS05: 0.4 kg
Type AS05
Voltage 4.5 V to 18 V DC
Current 35 mA typical
Frequency GPS L1 1575.42 MHz
GLONASS L1 1602.5625 MHz-1611.5 MHz
Gain (typically) 27 dBi
Noise Figure (typically) < 2 dBi
Type Operating temperature [°C] Storage temperature [°C]
AS05 -40 to +70 -55 to +85
Type Protection
AS05 IP68 (IEC 60529)
Dust tight
Protected against water jets
Protected against continuous immersion in water
Tested for 2 h in 1.40 m depth
Type Protection
AS05 Up to 100 %
The effects of condensation are to be effectively counter-
acted by periodically drying out the antenna.
Separation distance from instrument to antenna Supplied cable lengths [m]
GS05/GS06 AS05 1.2
