Leister Uniplan E - TOOL DESCRIPTION; Main Components; Operating Components; Steering Equipment

3
TOOL DESCRIPTION Overlap 20/30 mm LEISTER Uniplan E
1
2
17
18
3
78
4
25 12
24 23
13
14
9
6
22
5
27 26
19
20
Main components
1. Housing/chassis
2. Mains cable
3. Hot air blower
4. Welding nozzle
5. Connection hose
6. Drive/pressure roller
7. Pressure belt
8. Guide roller
9. Drive roller
10. Steering roller
11. Lifting device
12. Support bracket
13. Air filter
14. Manual air vane
15. Display
15
21
Operating components
16. Lifting device lever
17. Main switch
18. Drive switch
19. Potentiometer for welding speed
20. Potentiometer for air flow
21. Potentiometer for air temperature
22. Swivel lever
Steering equipment
23. Guide roller lever
24. Guide roller knob
25. Guide roller
Automatic drive
26. Switch pin
27. Set screw
