Unity Motorhome
96
Water and Plumbing System
Potable Water
When a city water supply connection is not
available, ll the fresh water tank using the
following procedure:
1. Fill a suitable water container with potable
water.
2. Place the suction hose (6) attached to the
winterize by-pass valve into potable water
container.
NOTE: The winterize by-pass valve (7)
is located in the exterior utility center.
3. Turn the winterize by-pass valve (7) to
“WINTERIZE,” and water ll selector valve
(2) to water tank ll (A).
4. Turn on the water pump switch (5) on the
system monitor panel.
5. Depress and hold the fresh water tank level
switch (3) to show the percent-full level on
the LED display (4). Once the fresh water
level reads full on the LED display, turn off
the water pump.
6. Turn the winterize by-pass valve (7) to
“NORMAL FLOW,” and the water ll selector
valve (2) to city water (B).
Water Pump Switch
When the water pump switch (1) is in the “ON”
position, the water pump will automatically
activate when using the shower, toilet, or any
faucet. The water pump switch is located on the
system monitor panel in the cabinet above the
coach entrance.
NOTICE
Always turn off the water pump switch (1)
if leaving the motorhome unattended for an
extended period of time and when driving
to prevent excessive damage and battery
discharge in the event of a leak.
6
7
1
