Leisure UNITY 2017 - Corner Bed; Seating;Sleeping

Unity Motorhome
67
Appliance and Equipment Operation
Corner Bed
Seating/Sleeping
(Varies According to Floor Plan)
Booth Dinette Bed (1) Conversion
1. Pull the table release handle (2) downwards,
and lower the table until it is level with the
seating base.
2. Arrange the seat cushions as shown in
Figure (3).
2
1
6
3
Booth Dinette Bed U Lounge (4) Conversion
1. Pull the table release handle (5), and lower
the table until it is level with the seating base.
2. Arrange the seat cushions as shown in
Figure (6).
5
5
