Unity Motorhome
91
Electrical System Operation
2
Rear Indicator/Reverse/Brake/Road Lights
(1)
1. Unscrew the side marker lens cover (2).
2. Pull the light assembly (1) away from the
coach body.
3. Unclip the electrical connector (3) from the
light you are replacing.
4. Remove the two nuts (4) securing the
support bracket (5) to the light assembly,
and remove the support bracket.
5. Remove the defective light (6), and install a
new one.
NOTE: The lights (6) are sealed with
a bead of silicone to prevent dust
and moisture from entering the light
assembly (1). Carefully remove the
silicone when changing the light, and
apply a new bead before reinstalling the
light assembly.
6. Reinstall the light assembly (1) by following
Step 5 to Step 1 in reverse order.
1
3
4
5
6
3
1
