Leisure Unity - Water Heater Operation

Unity Motorhome
98
1
5
3
6
Caution
5
(Shown with exterior cover open)
Water Heater (Standard)
Operation
The water heater (1) is designed to operate
using LP gas or 120 volt C power The water
heater is accessible from both outside and
inside the coach To open eterior cover 2, lit
and turn latch 3
Operating on 120 volt AC power
1. Turn on the electrical shut o switch , and
turn on the water heater switch  on the
system monitor panel. The water heater will
automatically start.
Operating on L as
1. Turn on the propane shut o switch 5 and
turn on the water heater switch  on the
system monitor panel. The water heater will
automatically light.
4
Ensure there is water in the hot water tank
to prevent burning out the heating element
when the power is turned on.
2
Water  lumbing Sstem
O
Always refer to the owner’s manual for the
water heater (included in your motorhome
information kit).
