nverter emote Control anel
The Inverter Remote Control Panel (8) is
located in the cabinet above the coach entrance
doorway. The Inverter Remote Control Panel
is euipped with an nverter unction  
 7 and a Charger unction   
switch. The Inverter/Charger System Status
isplay 3 shows the attery oltage, dierent
stages of Battery Charging, DC Power Usage
while Inverting, and many more....
Refer to the inverter remote control manual
in the Motor home Information Kit for more
information.
1. Power.
2 Fault.
3 Status Display.
 Charging LED.
5 Inverting LED.
 Charger Function ON/OFF.
7. Inverter Function ON/OFF.
NOTICE
The inverter remote control panel is factory-
congured for the specic inverter and
batter installed in our motorhome. f
modications are made to the batter ban
it ma be necessar to recongure the
remote. ave the unit serviced b authorized
personnel only.
NOTICE
The inverter may cause digital clocks
installed in small appliances, such as coffee
makers, to operate erratically or malfunction.
Avoid using digital clocks when operating
the inverter.
1
3
2
4
6
7
5
8
NOTICE
When the Inverter remote fault light (2) is on
and the displa 3 shows ead atter
chec to see if the batter disconnect switch
(9) is ON.
9
