Unity Motorhome
82
Electrical System Operation
O
lease be aware that inverters use a standb
current drain even when your equipment is
turned off so to ensure our batter life turn
off the inverter function when not in use.
NOTICE
The inverter is not intended for appliances
that consume more than the specied
inverter wattage. ceeding the specied
wattage could result in damage to the
appliance or the inverter. Extended use of
the inverter-powered receptacles will drain
our batteries.
Before performing any service, insure the
inverter is completely disconnected from
power sources. isconnect batter 12V C
and shore power (120V AC). Inverter should
onl be services b a ualied technician.
Inverter
Triple E RV/Leisure Travel Vans uses Magnum
1200W nverterCharges The 1200W inverters
are standard on all units. Inverters operate on
the ollowing principal they change 12 C
power stored in atteries into 120 C power
used in household appliances The 1200W
inverter can supply 10 C at ull capacity
it has a 15 output reaker 2 and a 20
input reaker 1 The 15 reaker powers the
Bedroom, Entertainment and Galley receptacle.
When the motor home is plugged into shore
power, the breaker panel supplies power to the
inverter, which switches that power through to
the ‘inverter loads’.
When shore power or generator power is
absent, the inverter can be switched on and
used to supply 120 volt power to the loads
mentioned above, no other receptacles will
have power The 1200 watt inverter has an
internal attery charger set to 55 aps nce
the inverter has accepted the AC input power,
Charge Mode will begin, however it is possible
to turn the charger function off.
The Magnum Monitor instrument is a complex
computer control and monitor device, it is
used on all nits t is actory congured or
the particular inverter and battery installation
Triple E RV/Leisure Travel Vans uses. If any
odications are ever ade to the attery
bank, it may be necessary to change some
internal parameters. Please refer to the Inverter
/ Remote Control manual for setting or contact
the anuacturer The agnu RC50
controls the invert and charge features of the
Inverter.
NOTICE
he invert feature needs to be manuall
switched ‘on’ and ‘off’, however when the
inverter Feature was turned ON and the
batter disconnect switch has been turned
off net time the nverter has been powered
up the inverter feature needs to be turned
on manually.
2
1
Caution
