Electrical System Operation
ower istribution anel
The power distribution panel (1), located in
a lower cainet ascia, contains the 120 volt
reakers or the C incoing power and 12 volt
uses 2 or the coach C attery power
The let side o the reaker panel  contains
120 volt C reakers Reer to the circuit
breaker panel decal to identify the function of
each reaker The right side 3 houses 12 volt
DC fuses. Refer to the circuit fuse panel decal
to identify the function of each fuse.
120 Volt AC Circuit Breakers
The circuit reaker panel protects all 120 volt C
equipment and components in the motorhome
from overload, a short in the wiring, or a short
in the component itself. In the event of an
overload, the circuit reaker cuts o the ow
of electricity in the system and helps prevent
daage or re
 a circuit reaker trips, allow a rie cool
down period o 3090 seconds, then reset the
reaker y turning it  and then  
a circuit reaker trips repeatedly, the circuit
is overloaded or there may be a short in the
wiring or in the equipment, and both should
e checked and serviced y ualied service
personnel. Refer to the converter and control
panel manuals in the Motorhome Information
Kit for further details.
O here is a single 3 amp main breaer
which protects the entire AC electrical
sstem. Chec the main breaer if the entire
electrical system will not function on shore
power or generator (if equipped).
