Unity Motorhome
1
Vehicle Operation
A
B
C
4
1
3
2
5
Slide Out Room Emergency Operation
If the slide out room fails to extend or retract
electrically, you can manually operate the slide
out mechanism. Manual operation of the slide
out is not recommended unless the slide out
needs to be retracted in order to move the
motorhome.
NOTICE
The slide out electrical function is protected
b a fuse located on the power distribution
panel. Chec that the fuse is intact before
resorting to manual slide out operation.
1. Turn the battery disconnect switch to the
position, and disconnect the shore
power. Refer to the Battery Disconnect
Switch section in the “Electrical System
peration chapter
2 Locate the control module (1) (installed in
lower galley.
3 nplug oth otor electrical connectors 2
3 ro the control odule 1
Reove the slide out snapon tri oards
(A, B, C) to access the motor mounting
screw on each side o the slide out, and
remove the screw.
5 Peel ack the eterior sweep gasket 5
from the top corners of the slide out, and lift
the slide out motor to release.
Push in the slide out room until fully retracted,
keeping both sides of the slide out level with
the coach while retracing.
O anual movement of the slide
out reuires signicant effort and ma
require the assistance of several people.
7. Peel ack the eterior sweep gasket 5
from the top corners of the slide out, and
reengage the slide out motor.
8. Replace the otor ounting screw on
each side of the slide out, and replace the
slide out snapon tri oards , , C
9 Reconnect oth electrical connectors 2
3 to the control odule 1
Do NOT move the motorhome unless the
slide out room motors electrical connectors
(2, 3) are connected to the control module
(1). Reconnecting the motor electrical
connectors to the control module applies a
brae to the slide out room motors eeping
the slide out room locked in position.
10 Install the travel lock before moving the
motorhome.
Caution
