Unity Motorhome
3
Vehicle Operation
1
2
3
4
5
Rotate the support leg 1 90 degrees and
swivel the support leg down.
5 Lit the retaining pin 2 on the coach awning
support bracket, and insert the support foot
plate 3 llow the retaining pin to drop
down and lock the foot plate in place.
Repeat steps 3, , 5, and to install the let
support leg.
7. nsure that the latches in the let and
right support legs are unlocked (raised).
8. Fully extend the awning by depressing
and holding the awning switch in the “OUT’
(extend) position.
9 Lift the lead rail of the awning to the desired
height and lock the let and right latches
O dust the side of the awning
furthest away from the coach door
to a slightl lower position to enable
rainwater to run off.
10 Turn on the awning light i desired 5
Retracting the Awning
1. Release and stow the legs by following the
steps in the Extending the Awning section in
reverse order.
2 Depress and hold the awning switch,
located on passenger side seat base, in the
retract position until the awning ully
retracts.
