4.4 Swath width
Swath width of the SPLENDIMO 240 MC mower/conditioner
is adjustable from 0,8 up to 1,6 m, while the swath width of
the SPLENDIMO 280 MC mower/conditioner can be varied
between 1,0 and 1,8 m. The swath width of the SPLENDIMO
320 MC mower/conditioner can be adjusted as from 1,4m.
• To adjust the swath boards you need to loosen the handles
and move them through the slotted holes until the required
opening has been obtained. Lock the handles again
36
10
