Should the machine hit an obstacle during mowing, it can
move backward thanks to the extension of the breakback
device (fig. 13).
• After extension of the breakback device: drive backwards a
few meters until the breakback device has locked back into
position.
Due to this procedure the PTO shaft between the tractor
and the machine is shortened. The PTO may not be too
long.
The machine is protected against overload by a slip clutch.
6 DISMOUNTING FROM THE TRACTOR
- Lower the machine.
- Switch off the tractor engine. Disengage the PTO shaft
from the tractor PTO.
- Place the PTO shaft in the hook (fig. 14).
- Set the parking jacks in the lowest position.
- Close the red hydraulic valve.
- Lower the three point hitch until the parking jacks are
supported by the ground.
- Depressurize the hydraulic system and disconnect the
hydraulic hoses.
- Disengage the top link from the machine.
- Uncouple the lower arms from the machine.
38
13
!
14
