14
Fuel Gauge
Note: e fuel gauge may vary slightly when your vehicle is moving or on a gradient.
Switch the ignition on. e fuel gauge will indicate approximately how much fuel is le in the fuel tank. e arrow
adjacent to the fuel pump symbol indicates on which side of your vehicle the fuel ller door is located. e needle
should move toward F when you refuel your vehicle. If the needle points to E aer adding fuel, this indicates your
vehicle needs service.
Aer refueling some variability in needle position is normal.
• It may take a short time for the needle to reach F aer fueling. is is normal and depends upon the slope of
pavement at the fueling station.
• e fuel amount dispensed into the tank is a little less or more than the gauge indicated. is is normal and
depends upon the slope of pavement at the fueling station.
• If the fuel station nozzle shuts o before the tank is full, try a dierent fuel pump nozzle.
Speedometer
e Speedometer displays the speed of the vehicle in MPH (Miles per Hour) and KPH (Kilometers per Hour). e
Speedometer is calibrated in accordance to the tire size.
Information Display
e Information Display can be used to control various systems on the vehicle using the information display
controls on the steering wheel. (See Page 89 in the Ford Owner’s Manual for more information).
Tachometer
e Tachometer shows the engine RPM’s (Revolutions per Minute).
Boost Gauge
e Boost Gauge displays pounds of boost being produce by the turbo charger.
Starting and Stopping (6.7L V8 Diesel)
Note: Make sure you are sitting in the correct position before adjusting steering wheel.
Read all starting instructions thoroughly before attempting to start the vehicle.
Before starting the engine on the vehicle make sure all occupants have fastened their seat belts. Make sure the head
lamps and electrical accessories are o. Apply the parking brake. Be sure the gearshi lever is in P (Park).
Turn the ignition key to the start position. e glow plug pre-heat indicator will illuminate in the dash.
