49
Warning: Use caution while closing turret lid. Be sure personnel and equipment are clear of the turret lid path
before closing. Failure to comply could result in equipment damage and injury to personnel.
Warning: Do not attempt to open or close the hatch lid while vehicle is in motion. Be sure lid is securely latched
in either the open or closed position before operating the vehicle. Failure to do so could result in personal injury.
Warning: Release of the rotation lock while vehicle is on steep grades can cause the hatch to turn.
Warning: Always be aware of low lying branches and power lines while operating out of the hatch. Failure to
comply can result in equipment damage, injury or death to personnel.
Note: It is recommended that the turret gear lock be engaged while ring a weapon from the platform.
Laptop / Ram Cam Monitor Platform
e Laptop / Ram Cam Monitor Platform utilizes a four hole bolt pattern that accepts an MDT telescoping post.
e platform is located at oor level on the right hand side of the center console. Remove the cover labeled “Laptop
/ Ram Cam Monitor Platform” to access the bolt holes.
Fuel Tank Access Cover
e Fuel Tank Access Cover located below oor level, directly inside the rear doors. e Fuel Tank Sender is
accessed through the oor by removing the rear carpet, and removing the access cover in the oor. e access
cover is retained with (4) 3/8-16 X 1¼” BHCS.
(4) 3/8-16 X 1 1/4” BHCS
Laptop / Ram Cam Monitor Platform
