48
e Roof Mounted Hatch is rotated by depressing the secondary red handle on the rotation gear lock and pulling
the primary red handle towards you to unlock the gear.
Manually rotate the hatch to the desired location utilizing the hand-holds that are built into the hatch riser and
engage the gear rotation lock. e hatch will spin 360 degrees and lock in any position.
Note: Do not use the gear rotation lock as a handle to turn the hatch.
Note: It is recommended that the turret gear lock be engaged while ring a weapon from the platform.
Warning: Release of the rotation lock while vehicle is on steep grades can cause the hatch to turn.
Warning: Always be aware of low lying branches and power lines while operating out of the hatch. Failure to
comply can result in equipment damage, injury or death to personnel.
A Gunport is located in the hatch lid. Push the gunport actuation handle with the palm of your hand, ngers open,
allowing the weight of the port to rotate the Ballistic plate. ere is a metal rain cover attached to the outside of the
hatch gunport which can be removed as needed. Once removed, the rain cover should be stowed inside the vehicle
until the hatch gunport is no longer in use.
Rotating Roof Turret (Military)
e rotating roof turret provides a protected gunner position on the roof of the vehicle. e Roof Mounted Rotating
Hatch is opened by releasing the rotary latch and pushing upward on the lid. To release rotary latch apply pressure
outward on the rotary latch handle. e counter balance hinge system allows the Ballistic lid to be lied easily.
When fully opened the hatch lid will lock in the upright position via a T-Handle Latch. To lower the lid; release
the T-Handle labeled “Hatch Release” located on the right side of the lid and pull the lid simultaneously into the
closed position using the interior grab handle.
e Turret position can be changed by depressing the secondary Red handle on the rotation gear lock and pulling
the handle toward you to unlock the gear. Use the Turret Gear Rotation Handle located to your le outside the
hatch to change the orientation of the turret. e Roof Turret will spin 360 degrees and lock in any position.
Primary Gear Lock Handle
Secondary Gear Lock Handle
Turret Rotation Gear Lock
G-4 Rotating Roof Turret
Military Turret
