When not in use the Ram Bars are stowed on the exterior brackets located on the driver side of the vehicle. e
side mounted carry brackets have slide pins with hitch pins and safety lanyards to secure the assembly during
transport. e push plate is secured in the hydraulic receiver at the front of the truck for transport.
e following procedure should be used as a basis for any standard breaching operation that utilizes the Ram Bar
System. Once the Ram Bar System has been deployed and is in place in the front receiver with slide pins engaged,
proceed to the object to be breached, ease up to the object and apply pressure with the front plate. With pressure
applied on the ram plate, drive forward with the vehicle keeping steady pressure until the breach is complete.
When backing out always keep the vehicle as straight as possible to avoid “Hooking” the front plate.
Warning: Failure to follow basic breaching procedures can result in equipment damage and or injury to
personnel.
ere is an optional Gas Injection Unit (GIU) and Ram Cam available as add-ons for the Ram Bar System.
Self-Contained Breathing Apparatus (SCBA)
e SCBA System consists of two 6000 PSI tanks mounted below oor level in a ballistic holder. Air ow is
controlled through an interior mounted regulator with quick connect ttings located throughout the vehicle
interior at ceiling level.
e regulator also includes a remote connection for relling the storage tanks. Based on a ten man team with
under stress air usage at 45 cu . ½ hr. the onboard air supply would last approximately .75-1.0 hrs.
Gunner Stand Military / Law Enforcement
Note: Conrm gunner stand is locked at the desired height before operation out of the hatch.
Note: Make sure lock pins are secured in place before attempting to stand on the platform.
Warning: When lowering the gunner stand to the stowed position; be sure the stand is free of obstructions.
e Gunner Stand is mounted on the oor below the Roof Mounted Hatch. e height can be adjusted to three
predetermined locations by liing up on the two handholds in the platform. e platform will lock with an audible
click at each location. e top position is approximately 20 inches above the vehicle oor.
e Gunner Stand can be lowered or fully closed by grasping the release pins located inside the handholds and
pulling in as the stand is guided into the lower positions.
Quick Connect Fitting
SCBA Regulator
To Next Page
