22
Table 5. System Status Descriptions
State (Icon) Icon Location Description
Technician Status
Screen
When the CS8500 (CS) has a fault state, this icon
would be displayed.
The following possible errors may have occurred
which would generate this system status:
• Local temperature sensor error
• External sensor error
• Memory error
• Humidity sensor error
• CO sensor error
Technician Status
Screen
No faults detected
