Lenovo Flex 7 - Remove the Camera

Figure 40. Remove six screws and remove the hinges
Screw specifications
Number of screws
M2.5 x L3 6
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Hinges
Remove the camera
Make sure the following FRUs (CRUs) have been removed.
“Disassemble the LCD unit” on page 48
“Remove the hinge cover” on page 48
“Remove the LCD panel and EDP cable” on page 48
Step 1. Disconnect the camera cable from the camera board and then remove the camera.
Figure 41. Disconnect the camera cable from the camera board and remove the camera
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Camera
52
Hardware Maintenance Manual
