Lenovo IdeaPad FLEX-14API - Chapter 6. Help and support; Frequently asked questions

1
1
1
1
1
1
1
1
1
1
Figure 1. Remove the 10 screws
Screw specifications Number of screws
M2.0 x 6 10
Step 2. Insert a pry tool to separate the lower case from upper case.
2
2
2
2
Figure 2. Separate the lower case from upper case
Step 3. Remove the lower case.
30
Hardware Maintenance Manual
