Lenovo IdeaPad FLEX-14API - Disassemble the LCD Module; Remove the LCD Panel

3
3
Figure 40. Open the hinges
Step 4. Slowly and carefully lift up the upper case.
4
Figure 41. Remove the upper case (with keyboard)
Disassemble the LCD module
The LCD module as a whole is not a FRU. Instead, it contains FRUs as its components. Before
disassembling the LCD module, make sure it has been detached from the upper case. Refer to “Remove the
upper case (with keyboard)” on page 48 for instructions.
Remove the LCD panel
Step 1. Carefully remove the strip cover.
Chapter 4. Removing a FRU or CRU 49
