1
Figure 42. Remove the strip cover
Step 2. Remove the 4 screws. Then, remove the hinge rubbers that secure the EDP cable and antenna
cables.
1
1
1
1
2
Figure 43. Remove the 4 screws and hinge rubbers
Screw specifications
Number of screws
M1.6 x 2 4
Step 3. Pull out the removable tapes with tweezers.
50
Hardware Maintenance Manual
