Figure 17. Remove the memory module
Remove the fingerprint board
Note: The fingerprint board is available on selected models.
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 29
“Remove the battery pack” on page 31
Step 1. Detach the fingerprint cable connector from the system board.
Figure 18. Detach the connector
Step 2. Remove 1 screw.
38
Hardware Maintenance Manual
