Figure 19.
Remove 1
screw
Screw
specifications
Number
of
screws
M2.0
x
3
1
Step
3.
Remove the
fingerprint board
bracket.
3
Figure 20.
Remove the
fingerprint
board
bracket
Step
4.
Remove the
fingerprint board.
Chapter 4
.
Removing a
FRU or
CRU
39
