Appendix A. Label locations
Figure 52. Label layout on the back side of the base cover
Labels attached to the base cover are country/region specific. Make sure to apply the appropriate labels to
the replacement base cover.
Table 4. All base cover labels
Label Label description Applied country/region Label dimensions
a
Rating POD label all country/region
100 mm x 30 mm
b GML label all country/region
16 mm x 22.5 mm
© Copyright Lenovo 2019 55
