Figure 44. Pull out the removable tapes
Step 4. Remove the LCD panel.
Figure 45. Remove the LCD panel
Remove the EDP cable, camera board, and microphone board
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 29
“Remove the battery pack” on page 31
“Remove the upper case (with keyboard)” on page 48
“Remove the LCD panel” on page 49
Step 1. Turn over the LCD panel. Then, detach the touch connector, LCD connector, and microphone
connector.
Chapter 4. Removing a FRU or CRU 51
