Replacing FRUs 45
Replacing the Wi-Fi antennas
Attention
Do not open your computer or attempt any repairs before reading the Important
Product Information Guide.
Replacing the front Wi-Fi antenna
1
Remove the computer cover. For details, see Removing the computer cover.
2
Remove the storage drive. For details, see Replacing the storage drive.
3
Remove the system fan. For details, see Replacing the system fan.
4
Remove the PCI Express card. For details, see Replacing the PCI Express card and PCI Express card
adapter.
5
Replace the front Wi-Fi antenna.
1 2
3 4
6
Reinstall the removed parts and computer cover. For details, see Completing the parts replacement.
