Replacing FRUs 49
Replacing the heat sink
Attention
Do not open your computer or attempt any repairs before reading the Important
Product Information Guide.
1
Remove the computer cover. For details, see Removing the computer cover.
2
Remove the storage drive. For details, see Replacing the storage drive.
3
Remove the internal speaker. For details, see Replacing the internal speaker.
4
Remove the system fan. For details, see Replacing the system fan.
5
Remove the PCI Express card. For details, see Replacing the PCI Express card and PCI Express card
adapter.
6
Replace the heat sink.
1 2
3 4
7
Reinstall the computer cover and reconnect the cables. For details, see Completing the parts
replacement.
