Table 26. Removal steps of LCD unit (continued)
Steps 5a are for ThinkPad Edge 14″ and E40, and steps 5b are for ThinkPad
Edge 15″ and E50.
5b
5b
5a
5a
5b
5b
5a
5a
Step Screw (quantity) Color Torque
5a or
5b
M2.5 × 6.5 mm, wafter-head, nylon-coated
(4)
Black 0.392 Nm
(4 kgfcm)
108 ThinkPad Edge 14″, Edge 15″, E40, and E50 Hardware Maintenance Manual
