Applying labels to the bottom cover
The new bottom cover FRU is shipped with a kit containing labels of several kinds. Apply those labels when
you replace the bottom cover. For the labels that are not shipped with the new bottom cover, peel them off
from the old bottom cover, and adhere them to the new one.
The following illustration shows the location of each label for the computer models.
1 GEO label 2 FCC label/Israel Homologation label/Indonesia Rating
and Postel label/Argentina CNC label
3 S/N label 4 CECP label IMEI label
5 Argentina Electrical Safety Label
6 Brazil Anatel label
7 ICASA system label 8 Malaysian SLP label
9 Genuine Microsoft label (Windows 10)
10 Asset tag label
11 IMEI label
12 Rating and information label
66 E480, E485, and R480 Hardware Maintenance Manual
