Lenovo ThinkPad E480 - 2030 Hinge Kit

2030 Hinge kit
For access, remove these FRUs in order:
• “1160 Keyboard bezel assembly and LCD unit” on page 78
• “2010 LCD bezel assembly” on page 83
• “2020 LCD panel” on page 84
Removal steps of the short hinge kit
Step Screw (quantity) Color Torque
1
M2.5 × 2.5 mm, flat-head, nylon-coated (6)
Black 0.294 Nm
(3.0 kgf-cm)
Chapter 9. Removing or replacing a FRU 85
