Remove the wireless LAN antennas assembly from the LCD rear cover assembly.
Antenna locations
a Wireless LAN main antenna (gray)
b Wireless LAN auxiliary antenna (black)
Peel off the stickers on the wireless LAN antennas assembly from the LCD rear cover assembly.
Attention: When you route the cables, ensure that they are not subject to any tension. Tension could cause
the cables to be damaged by the cable guides, or a wire to be broken.
Chapter 9. Removing or replacing a FRU 89
