2USB3.0connectors:UsedtoconnectdevicesthatarecompatiblewithUSB3.0andUSB2.0.
3Ethernetconnector:UsedtoconnectthedocktoanEthernetLAN.Theindicatorsonthisconnector
havethesamefunctionastheonesonthecomputer.
4DisplayPort
®
connector:Usedtoattachahigh-performancemonitor,adirect-drivemonitor,orother
devicesthatuseaDisplayPortconnector.
5Powerconnector:Usedtoconnecttheacpoweradapter.
6DVIconnector:UsedtoconnectamonitorthatsupportsDigitalVisualInterface(DVI)connection.
Note:TheDVIconnectorprovidesadigitalinterfaceonly.Thisconnectorcanonlybeusedwithacomputer
thatsupportsDVIconnection.
ToconnectaDVImonitor,dothefollowing:
•Turnoffthecomputer.
•ConnecttheDVImonitortotheDVIconnector.Thenconnectthemonitortoanelectricaloutlet.
•TurnontheDVImonitorandthenthecomputer.
7LenovoOneLinkconnector:ConnecttheLenovoOneLinkconnectortothecomputer.
